Parameters accessible with Function Code 03, 06,10h
Custom map parameters
Revision 13 HC900 Process Controller Communications User Guide 99
April 2017
Table 6-35 Custom map XYR6000 Transmitter block parameters
Parameter Name
Access
Notes
PV1
R
float 32
PV2
R
float 32
PV3
R
float 32
PV4
R
float 32
Elec Failure
R
unsigned 16
Mech Failure
R
unsigned 16
Input Failure
R
unsigned 16
Output Failure
R
unsigned 16
Low Battery
R
unsigned 16
External Power
R
unsigned 16
Config Error
R
unsigned 16
Calibration Error
R
unsigned 16
Radio Error
R
unsigned 16
Memory Error
R
unsigned 16
Firmware Error
R
unsigned 16
Watchdog Error
R
unsigned 16
Diagnostic
R
unsigned 16
Device Status
R
unsigned 32
Table 6-36 Custom map UDC Loop block parameters
Parameter Name
Access
Notes
Loop1 PV
R
float 32
Loop1 WSP
R
float 32
Loop1 Output
R/W
float 32
Loop1 LSP1
R/W
float 32
Loop1 LSP2
R/W
float 32
Loop1 LSP3
R/W
float 32
Loop1 LSP4
R/W
float 32
Loop1 Mode Auto/Manual
W
unsigned 16
Loop1 Mode Local/Remote
W
unsigned 16
Loop1 Mode A/M/L/R
R
unsigned 16
Loop1 Ramp SP
R/W
float 32
Loop1 LSP Select
R/W
unsigned 16
