Parameters accessible with Function Code 03, 06,10h
Stage
78 HC900 Process Controller Communications User Guide Revision 13
April 2017
6.12 Stage
Summary
This section contains addresses for the Stage function blocks.
See the Stage Register Maps in Table 6-1 for starting and ending addresses (hex) for Stage #1 through
Stage #8 Map Addresses.
The Modbus Stage number address for a Stage block can also be obtained from the Process Control Designer
report.
Function Code Support:
Reads – Function Code 3
Writes – Function Code 16 (10 hex) for preset of multiple registers (e.g., for floating point)
Writes – Function Code 6 for presetting an integer value
For custom addresses view or print a report in HC Designer.
Table 6-22 Stage Parameters
Fixed
Address
(hex)
Fixed
Register
(decimal)
Parameter Name
Access
Notes
6200
25089
PV1
R
Floating Point in Engineering Units
6202
25091
PV2
R
Floating Point in Engineering Units
6204
25093
Stage #1-4
Override Status
R
Bit Packed:
Bit 0: Stage #1 Override Active: 0=NO, 1=YES
Bit 1: Stage #1 Override ON: 0=OFF, 1=ON
Bit 2: Stage #2 Override Active: 0=NO, 1=YES
Bit 3: Stage #2 Override ON: 0=OFF, 1=ON
Bit 4: Stage #3 Override Active: 0=NO, 1=YES
Bit 5: Stage #3 Override ON: 0=OFF, 1=ON
Bit 6: Stage #4 Override Active: 0=NO, 1=YES
Bit 7: Stage #4 Override ON: 0=OFF, 1=ON
Bits 8-15: Unused
6205
25094
Stage #1-4 PV
On/Off Comparison
R
Bit Packed:
Bit 0: Stage #1 On Comparitor: 0=PV1, 1=PV2
Bit 1: Stage #1 Off Comparitor: 0=PV1, 1=PV2
Bit 2: Stage #2 On Comparitor: 0=PV1, 1=PV2
Bit 3: Stage #2 Off Comparitor: 0=PV1, 1=PV2
Bit 4: Stage #3 On Comparitor: 0=PV1, 1=PV2
Bit 5: Stage #3 Off Comparitor: 0=PV1, 1=PV2
Bit 6: Stage #4 On Comparitor: 0=PV1, 1=PV2
Bit 7: Stage #4 Off Comparitor: 0=PV1, 1=PV2
Bit 8-15: Unused
