Parameters accessible with Function Code 03, 06,10h
Overview
Revision 13 HC900 Process Controller Communications User Guide 43
April 2017
partitions
parameters to contiguous addresses.
Which parameters can be mapped?
Function Block
Category/Filter Selection
Available in Fixed
Map
Available in
Custom Map
AGA8-Detail Block
AGAs
No
Yes
AGA8-Gross Block
AGAs
No
Yes
Alternator Block
Alternators
Yes
Yes
XYR5000 Base Station Block
Communications
No
Yes
XYR5000 Transmitter Block
Communications
No
Yes
XYR6000 Transmitter Block
Communications
No
Yes
UDC Loop Block
Communications
No
Yes
UDC Loop2 Block
Communications
No
Yes
Calendar Event Block
Counters/Timers
No
Yes
Device Control Block
Device Controls
Yes
Yes
Hand Off Auto Block
Hand Off Autos
Yes
Yes
Four Selector Switch Block
Logic
No
Yes
Push Button Block
Logic
No
Yes
PID Loop Block
Loops
Yes
Yes
On Off Loop Block
Loops
Yes
Yes
Carbon Loop Block
Loops
Yes
Yes
Three Pos. Step Cont. Block
Loops
Yes
Yes
Auto Manual Bias Block
Loops
Yes
Yes
Set Point Programmer Block
Programmers
Yes
Yes
Ramp Block
Ramps
Yes
Yes
Set Point Scheduler Block
Schedulers
Yes
Yes
Sequencer Block
Sequencers
Yes
Yes
Stage Block
Stages
Yes
Yes
Position Proportional Output Block
NA
No
No
Peer-Peer Block
NA
No
No
Modbus Slave Block
NA
No
No
Modbus/TCP Slave Block
NA
No
No
XYR6000 Gateway
NA
No
No
For parameters available only in a custom map, see section 6.18.
