Parameters accessible with Function Code 03, 06,10h
Fixed Map
Revision 13 HC900 Process Controller Communications User Guide 45
April 2017
Fixed
Start
Address
(hex)
Fixed
End
Address
(hex)
Item Description
See
section
1640
16FF
Loop #23 (floating point & bit packed)
1740
17FF
Loop #24 (floating point & bit packed)
1800
187F
Analog Input Value (#1-#64) First 8 slots of Rack #1 only - Function Code 03
6.5
18C0
1D6F
Variable Value (#1 - #600)
6.6
1DF0
1DF6
Time
6.7
1E00
1E0F
Set Point Programmer #1
6.8
1E10
1E1F
Set Point Programmer #2
1E20
1E2F
Set Point Programmer #3
1E30
1E3F
Set Point Programmer #4
1F00
1F3F
Set Point Programmer #1 (Additional Values)
1F40
1F7F
Set Point Programmer #2 (Additional Values)
1F80
1FBF
Set Point Programmer #3 (Additional Values)
1FC0
1FFF
Set Point Programmer #4 (Additional Values)
2000
27CF
Signal Tags (#1 - #1000) (legacy)
6.9
2800
29FF
Set Point Programmer #1 Segments
6.8
2A00
2BFF
Set Point Programmer #2 Segments
2C00
2DFF
Set Point Programmer #3 Segments
2E00
2FFF
Set Point Programmer #4 Segments
3000
304F
Scheduler #1 Value
6.10
3050
309F
Scheduler #2 Value
3200
3B5F
Scheduler #1 Segments
3B60
5A9F
Signal Tags (#1 - #4000) (HC900)
6.9
5AA0
5ABF
Sequencer #1 Parameters
6.11
5AC0
5CBF
Sequencer #1 Step 1 Table (64 steps in sequence)
6.11
5CC0
5CFF
Sequencer #1 State Table
6.11
5D00
5D1F
Sequencer #2 Parameters
6.11
5D20
5F1F
Sequencer #2 Step 1 Table (64 steps in sequence)
6.11
5F20
5F5F
Sequencer #2 State Table
6.11
5F60
5F7F
Sequencer #3 Parameters
6.11
5F80
617F
Sequencer #3 Step 1 Table (64 steps in sequence)
6.11
6180
61BF
Sequencer #3 State Table
6.11
6200
6227
Stage #1
6.12
6230
6257
Stage #2
6260
6287
Stage #3
6290
62B7
Stage #4
62C0
62E7
Stage #5
62F0
6317
Stage #6
6320
6347
Stage #7
6350
6377
Stage #8
6400
642D
Ramp #1
6.13
6430
645D
Ramp #2
6460
648D
Ramp #3
