| 85
Document 800-26311_ A - February 2020
1. Click Outputs on the Doors configuration window to open the Outputs configuration
pane.
Figure 3-6 Door Outputs Configuration Interface
2. Enter an Output Name.
3. Configure the following general settings.
Configuration Description
Pulse Specifies the duration for which the device will assume abnormal
status. For example, it specifies how long a horn will sound or a
door strike will remain released. The maximum length of time is 1
hour, 45 minutes, 59 seconds.
You can express seconds in tenths of a second.
Latch Toggles the state of the outputs between energized and
de-energized status upon every activation (code use, interlock, or
manual pulse).
