MPA1 User Guide
4. Configure the following schedule settings.
5. Click Save.
Reporting
Generating Event Reports
On the Alarms & Events window, you can download Alarms/Events or Web events.
1. Click to open the menu, then click Alarms & Events or Web Events.
Interlocks Enables you to disable the interlock, or programmed interaction
between two points. When enabled, this point ignores all interlock
actions to it, effectively disabling it from being a Reacting
Component.
TZ Card Toggle Requires, like the First Card Rule, a valid card read within the
schedule to enable the schedule (period in which doors are
unlocked) to take effect. Unlike the First Card Rule, however, the
user can swipe the card a second time to return the doors to a
locked state.
Note Both TZ Card Toggle and First Card Rule cannot be
enabled at the same time. Appears only on door lock
outputs.
First Card Rule Requires a valid card read within the schedule to enable the
schedule (period in which doors are unlocked) to take effect.
Note Both TZ Card Toggle and First Card Rule cannot be
enabled at the same time. Appears only on door lock
outputs.
Configuration Description
Configuration Description
Energized Sets the period during which the output is automatically
energized.
Disable
Interlocks
Sets the period during which the interlock, a programmed
interaction between selected inputs, outputs, and groups will be
disabled. During the selected Schedule, this point ignores all
interlock actions to it, effectively disabling it from being a
Reacting Component during the Schedule. Outside of the
Schedule the point will react to interlocks as expected.
