FireWarden 100-2/E — P/N 52778:A 11/04/2005 11
Section 1: Product Description
The NotifierFireWarden-100-2 is a combination FACP (Fire Alarm Control Panel) and DACT
(Digital Alarm Communicator/Transmitter) all on one circuit board. This compact, cost effective,
intelligent addressable control panel has an extensive list of powerful features which offer the latest
in fire protection technology. The power supply and all electronics are contained on a single circuit
board housed in a metal cabinet, providing a complete fire control system for most applications.
Optional modules, which plug into the main circuit board, are available for special functions.
Available accessories include LED, graphic and LCD annunciators, reverse polarity/city box
transmitter, local and remote upload/download software and remote power expansion.
The integral DACT transmits system status (alarms, troubles, AC loss, etc.) to a Central Station via
the public switched telephone network. It also allows remote and local programming of the control
panel using the Programming Upload/Download utility. In addition, the control panel may be
programmed or interrogated off-site via the public switched telephone network. Any personal
computer with Windows™ 95 or greater, and compatible modem with a speed of 14.4 kbps or
faster and Upload/Download software kit, may serve as a Service Terminal. This allows download
of the entire program or upload of the entire program, history file, walktest data, current status and
system voltages.
Inventory
When the NFW2-100 shipment is received, check to make certain that all parts have been included
in the shipment. The NFW2-100 shipment should consist of one of each of the following:
✓ main circuit board with display, transformer and chassis
✓ backbox with door
✓ plastic bag containing screws, cables, key, etc.
✓ manual
1.1 Features and Options
• New LiteSpeed™ polling protocol for faster SLC response time
• SLC operates up to 10,000 ft. (3,000 m) with twisted, unshielded wire (refer to “Wire
Requirements” on page 173)
• Built-in DACT (Digital Alarm Communicator/Transmitter)
• Single addressable SLC loop which meets NFPA Style 4, 6 and 7 requirements
• 198 addressable device capacity (99 detectors and 99 control/relay/monitor modules)
• 99 software zones
• Onboard NACs (Notification Appliance Circuits) which can be configured as four Style Y
(Class B) or two Style Z (Class A) circuits - special application
• 3.0 amps total power for NACs and 24 VDC special application auxiliary power outputs
expandable to 6.0 amps
• 3.6 amps total system power (includes battery charger) expandable to 6.6 amps
• Two programmable relay outputs and one fixed trouble relay
• Synchronization output for remote power supply applications (special application)
• Built-in Programmer
• Telephone Line Active LEDs
NOTE: The Notifier FireWarden-100-2 FACP (Fire Alarm Control Panel) will be referred to as the
NFW2-100. Unless otherwise specified, the term NFW2-100 is used in this manual to refer to
both the NFW2-100 (120 VAC version) and the NFW2-100E (240 VAC version) FACPs.
