168 FireWarden 100-2/E — P/N 52778:A 11/04/2005
Appendix B: Default Programming
The following table provides a list of the programming options and their factory default settings.
Program Option Factory Default Program Option Factory Default
Detector Programming Not Installed Daylight Savings Yes
Detector Type Smoke-Photo Month Start Daylight Savings April
Detector Verification Off Week Start Daylight Savings 1st Week
Detector Walktest Yes Month End Daylight Savings October
Detector PAS No Week End Daylight Last Week
Detector Presignal No Verification No
Detector Zone Assign. 000 only (future)
Detector Adj/Noun none PAS Timer 0
Module Programming Not Installed Presignal Timer 0
Module Type Monitor Waterflow Retard Timer 0
Module Walktest Yes NAC 1, 2, 3 & 4 Enable Enabled
(not used) NAC 1, 2, 3 & 4 Silenceable Yes
Module Presignal No NAC 1, 2, 3 & 4 Type Bell
Module Zone Assign. 000 only NAC 1, 2, 3 & 4 Sync Type System Sensor
Module Adj/Noun none NAC 1, 2, 3 & 4 Autosilence 0
Zone 0 Enable Enabled NAC 1, 2, 3 & 4 Coding Steady
Zone 1 Enable Enabled NAC 1, 2, 3 & 4 Zones Zone 000 only
Zone 2 Enable Enabled NAC 1, 2, 3 & 4 Silence Inhibit 0
Zone 3 Enable Enabled Relay 1 Alarm
.........................through.......... ..................... Relay 2 Trouble (fixed)
Zone 96 Enable Enabled Relay 3 Supervisory
Zones 97, 98 & 99 Enabled (future) No
(future) Annunciator Terminal Mode No
Loop Style Style 4 Annunciator ACS Mode
Loop Protocol CLIP UDACT No
Trouble Reminder Off ACS Installed No
Banner Honeywell Life Safety Onboard DACT No
Time Format 12 Hr Printer-PC No
Hours Setting 12 Printer Baud 9600
Minutes Setting 00
Second Settings 00
AM-PM Setting AM
Month Setting 01
Day Setting 01
Year Setting 00
