Appendix D: Wire Requirements
T-tapping of the SLC loop wiring is allowed for 2-wire (Style 4) configurations. The total
resistance of any branch cannot exceed 40 ohms. The total wire length of all branches cannot
exceed 10,000 feet (3,000 m).
Connecting external system accessories to the NFW2-100 main circuits must be carefully
considered to ensure proper operation. It is important to use the correct type of wire, wire gauge
and wire run length for each NFW2-100 circuit. Reference the chart below to specify wire
requirements and limitations for each NFW2-100 circuit.
Note: If the SLC loop is to be run in conduit with Notification Appliance Circuits, the risk of
encountering problems can be greatly reduced by exclusively employing electronic sounders (such
as MA/SS-24D) instead of more electronically noisy notification appliances such as
electromechanical bells or horns.
Table D.1 NFW2-100 Wire Specifications
CIRCUIT CONNECTIONS WIRE REQUIREMENTS
Circuit Type Circuit Function Wire Type and Limitations
Recommended
Max. Distance
Feet (meters)
Wire Gauge and Compatible Brands
SLC loop
(power-limited)
Connects to
Addressable
Devices
Twisted pair, 40 ohms
maximum per length of
Style 6 and 7 loops. 40
ohms per branch maximum
for Style 4 loops
*
10,000 (3,000 m)
8,000 (2,400 m)
4,875 (1,450 m)
3,225 (980 m)
12 AWG (3.1 mm
2
): Genesis WG-4315,
WG-4515, Belden 5020UL, 6020UL
14 AWG (2.00 mm
2
):Genesis WG-4313,
WG-4513, Belden 5120UL, 6120UL
16 AWG (1.30 mm
2
): Genesis WG-4311,
WG-4511, Belden 5220UL, 6220UL
18 AWG (0.78 mm
2
): Genesis WG-4306,
WG-4506, Belden 5320UL, 6320UL
Untwisted, unshielded pair 3,000 (900 m)
12-18 AWG (3.25 - 0.75 mm
2
)
ACS/TERM
(EIA-485)
(power-limited)
Connects to
annunciator
modules
Twisted, shielded pair with a
characteristic impedance of
120 ohms
6,000 (1,800 m)
18 AWG (0.75 mm
2
)
EIA-232
(power-limited)
connects to
remote printer
and PC computer
Twisted, shielded pair 50 (15 m)
18 AWG (0.75 mm
2
) minimum
Monitor Module
(power-limited)
Initiating Device
Circuit
Maximum loop wire
resistance is 40 ohms for the
Monitor Module and 20
ohms for the mini-module
2,500 (760 m)
12-18 AWG (3.25 - 0.75 mm
2
)
Monitor Module
for 2-wire
smokes
(power-limited)
Initiating Device
Circuit
No more than a 2.4 volt drop
allowed at end of circuit.
Maximum loop wire
resistance is 25 ohms
2,500 (760 m)
12-18 AWG (3.25 - 0.75 mm
2
)
Control Module
(power-limited)
Notification
Appliance
Circuit
In alarm, no more than a 1.2
volt drop allowed at end of
circuit
Distance limitation
set by 1.2 volt
maximum line
drop
12-18 AWG (3.25 - 0.75 mm
2
)
24 VDC
filtered
resettable
(power-limited)
Connects to
4-wire smoke
detectors
No more than 1.2 volt drop
allowed from supply source
to end of any branch
Distance limitation
set by 1.2 volt
maximum line
drop
12-18 AWG (3.25 - 0.75 mm
2
)
24 VDC
nonresettable
(power-limited)
Connects to
control modules,
annunciators and
accessories
No more than 1.2 volt drop
allowed from supply source
to end of any branch
Distance limitation
set by 1.2 volt
maximum line
drop
12-18 AWG (3.25 - 0.75 mm
2
)
CHG-120 or
CHG-75
Remote
secondary power
source
12 AWG (3.25 mm
2
) in
conduit
20 (6 m)
12-18 AWG (3.25 - 0.75 mm
2
)
* When using untwisted, unshielded wire, full conduit is recommended for optimum EMI/RFI protection.
