FireWarden 100-2/E — P/N 52778:A 11/04/2005 39
Section 3: Programming
3.1 Programming Data Entry
Programming can be accomplished using the NFW2-100 keypad or by connecting an optional
standard computer keyboard. The keyboard can be connected to the PS-2 connector J3 on the
control panel main circuit board.
The information presented in this section refers to programming the NFW2-100 via the onboard
keypad. If an optional computer keyboard is connected to the NFW2-100 main circuit board, the
following table describes the keyboard keys which correspond to the onboard keypad keys.
NOTICE TO USERS, INSTALLERS, AUTHORITIES HAVING JURISDICTION
AND OTHER INVOLVED PARTIES
This product incorporates field-programmable software. In order for the product to comply with the requirements in the
Standard for Control Units and Accessories for Fire Alarm Systems, UL 864, certain programming features or options must
be limited to specific values or not used at all as indicated below:
Program feature
or option
Permitted in
UL 864? (Y/N)
Possible settings
Settings permitted
in UL 864
Trouble Call Limit N
Refer to “Trouble Call Limit (Dialer Runaway Preven-
tion)” on page 99.
Trouble Call Limit = 0 (factory default): unlimited
calling to Central Station for any trouble condition
Trouble Call Limit = 1 - 99: limits call for each unique
trouble to from 1 to 99 within a 24 hour period
Trouble Call Limit
= 0 for unlimited
Central Station
trouble calls
Keypad Keys Computer Keyboard Keys
1st Event Home
CLR Delete
ESC Esc
RECALL Insert
**
##
A - Z A - Z
0 - 9 0 - 9
(on QZ key)
Space bar
——
//
••
ENTER Enter
ACK/STEP F1
SILENCE F2
DRILL F3
RESET F4
