FireWarden 100-2/E — P/N 52778:A 11/04/2005 93
Master Programming Level Programming
3.6.9 Option Modules
Options available for the NFW2-100 include ACS Series, Graphic and LCD annunciators, printer
connection for acquiring hardcopy printouts of panel data and PC (Personal Computer) connection
for uploading and downloading panel data.
Pressing 3 while viewing Programming Screen #3 will display the following screen:
Note that PR4800 in the display indicates that a supervised printer, configured for 4800 baud, has
been previously programmed into the system.
Annunciators/UDACT
Pressing 1 while viewing the Options Screen will cause the control panel to display the following
screens:
A Terminal Mode annunciator* and ACS Mode annunciator can be installed in the NFW2-100
system. To enable any of these devices, press the number corresponding to the selected device
shown in Annunciator Screen #1 so that Yes appears in the display to the right of the device. Each
press of the corresponding number key will cause the display to toggle between Enabled Yes and
Enabled No.
PROGRAMMING
1=HISTORY
2=WALKTEST
3=OPTION MODULES
Programming Screen #3
OPTION MODULES
1=ANNUNCIATORS/UDACT
2=ONBOARD DACT
3=PRINTER/PC PR4800
Options Screen
ANNUNCIATOR
1=TERM ENABLED YES
2=ACS ENABLED YES
3=UDACT YES
Annunciator Screen #1
ANNUNCIATOR
1=ACS INSTALLED
Annunciator Screen #2
NOTE:
1. *The FDU-80 is a Terminal Mode annunciator. To enable the NFW2-100 for FDU-80 operation,
program Term Enabled to Yes.
2. The Terminal Mode annunciator (FDU-80) and the Printer/PC use the same TB8 terminal block
on the NFW2-100 main circuit board. Only one device can be connected at one time, therefore,
programming Term Enabled to Yes will disable any Printer/PC communications.
