Honeywell NOTIFIER FireWarden-100-2 User Manual

FireWarden 100-2/E — P/N 52778:A 11/04/2005 111
Master Programming Level Programming
Report Style
Pressing 3 while viewing Central Station Screen #2 will cause the Report Style display to toggle
between Point and Zone. Setting the Report Style to Point will program the DACT to report
individual point status to the Central Station. The control panel is capable of monitoring a total of
198 addressable devices. Setting the Report Style to Zone will program the DACT to report zone
status to the Central Station. The control panel is capable of monitoring a total of 99 individual
zones.
 Manual Dial Mode
Pressing 3 while viewing On Board DACT Screen #2 will cause the following screen to be
displayed:
Pressing 1 for Primary Phone or 2 for Secondary Phone will display the following screen:
Pressing 1 for Go Off Hook will cause the DACT to access the selected phone line (similar to
taking the phone handset off the cradle). The selected phone line’s red Active LED will turn on.
Pressing 2 for Dial Digit(s) will display a screen which allows the user to key in the phone number
to be dialed. The first digit is keyed in and then the right arrow key is pressed to move the cursor to
the next position. The next digit is keyed in and the process is repeated until all digits have been
entered. Pressing the Enter key will cause the number just entered to be dialed.
Pressing 3 for Go On Hook will cause the DACT to hang-up, deselecting the previously selected
phone line. The phone line’s red Active LED will turn off.
CENTRAL STATION
1=PRIMARY
2=SECONDARY
3=REPORT STYLE POINT
Central Station Screen #2
NOTE:
1. Detector Address 01 will be reported to the Central Station as Point 01, Detector Address 02
as Point 02, with reports continuing in a similar fashion all the way up to Detector Address 99
which will be reported as Point 99.
2. Module address 01 will be reported to the Central Station as Point 160, Module Address 02
will be reported to the Central Station as Point 161, with reports continuing in a similar fashion
all the way up to Module Address 99 which will be reported as Point 258.
ON BOARD DACT
1=SERVICE TERMINAL
2=CENTRAL STATION
3=MANUAL DIAL MODE
On Board DACT Screen #2
MANUAL DIAL MODE
1=PRIMARY PHONE
2=SECONDARY PHONE
MANUAL DIAL MODE
1=GO OFF HOOK
2=DIAL DIGIT(S)
3=GO ON HOOK
