Master Programming Level Programming

2. With the cursor on the first letter of the Noun field, press the zero key twice to recall the

display ROOM_304. The cursor automatically jumps from the first to the last letter of the

Noun field

3. With the cursor on the last letter of the Noun field, press the zero key again to increment the

room number to 305

4. Press the right arrow key to advance the zone field

5. Select a zone number from 00 to 99. Z00 (default zone) is the general alarm zone. Z01

through Z99 may be selected to link software zones

Module Programming

Pressing 2, while viewing Point Program Screen #2, will allow the programmer to add, delete or

change the programming of an addressable module. The following screen will be displayed by the

control panel:

 Add Module

Pressing 1 while viewing the Modules Screen will display the following screen which allows the

programmer to add a new module address to programming:

A flashing cursor will appear in the position of the first asterisk to the left. The programmer keys in

the three digit module address, such as 005.

When the last digit is keyed-in, the following screen will be displayed:

POINT PROGRAM

SELECT TYPE

1=DETECTOR

2=MODULE

Point Program Screen #2

MODULES

1=ADD

2=DELETE

3=EDIT

Modules Screen

ADD MODULE

ENTER MODULE#

***

Add Module Screen #1

ADD MODULE

1=CONTROL

2=MONITOR

Add Module Screen #2
