Honeywell PC42d User Manual

Chapter 1: About the Printer
2 User Instructions for PC42d Desktop Printer
About PC42d printer
PC42d is a compact, lightweight, reliable and easy-to-use printer. It is capable of
printing up to 1,000 labels daily. Its features include:
• Printing resolution of 203 dpi (8 dots/mm);
• Printing speed: 2 to 4 ips (inches per second);
• It can be connected to storage devices, scanners or the USB port of a keyboard;
• It can also be connected to USB port of a PC;
• It supports programming languages for printers including Direct Protocol, ZSim
and ESim etc.;
• Optional, factory-installed Ethernet port;
• Optional, factory-installed RS-232 serial port.
Printer features
Use the illustration below to find the printer’s features
PC42d front panel
Medium window
LED status indicator light
Power switch
Upper cover handle
Printer button

Honeywell PC42d Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Display	-
Product color	Black
Ethernet LAN	Yes
USB 2.0 ports quantity	1
Flash memory	128 MB
Internal memory	64 MB
Built-in barcodes	1D, 2D, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code
Core diameter	38.1 mm
Maximum label width	110 mm
Maximum label length	0.99 m
Maximum roll diameter	128 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	15 - 80 %

Weight and Dimensions

Depth	174 mm
Width	184 mm
Height	222.5 mm
Weight	1500 g
