Honeywell PC42d User Manual

Chapter 3: Printer Troubleshooting and Maintenance
User Instructions for PC42d Desktop Printer 33
Cleaning the roller
During maintenance of standard printer, remove, clean and re-install roller in
accordance with the procedure below. Each time you install medium you should check
whether there is debris on the roller. If it is dirty it should be cleaned.
Note: Use of hard or sharp tools to remove jammed labels or other materials is strictly
prohibited. As the roller is highly precise it can be easily damaged.
1. Switch off the printer and remove its power supply;
2. Open the printer’s cover by turning the handles on both sides of the printer;
3. Remove the installed medium;
4. Push the spring lock on both sides of the roller inwards such that the roller is
inclined upwards.

Honeywell PC42d Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Display	-
Product color	Black
Ethernet LAN	Yes
USB 2.0 ports quantity	1
Flash memory	128 MB
Internal memory	64 MB
Built-in barcodes	1D, 2D, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code
Core diameter	38.1 mm
Maximum label width	110 mm
Maximum label length	0.99 m
Maximum roll diameter	128 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	15 - 80 %

Weight and Dimensions

Depth	174 mm
Width	184 mm
Height	222.5 mm
Weight	1500 g
