Honeywell PC42d User Manual

Appendix A - Specifications
User Instructions for PC42d Desktop Printer 37
Printer Specifications
PC42d Physical Specifications
Measurements:
184 mm x 222.5 mm x 174 mm
(7.3 in x 8.8 in x 6.9 in)
Weight:
1.5 kg (3.3 lbs)
Power Requirements:
100-240 VAC, 50-60 Hz, 1.5 A
Work Temperature:
5 °C - 40 °C (41 °F - 104 °F)
Storage Temperature:
-40 °C - 60 °C (-40 °F - 140 °F)
Relative Humidity:
15 - 80% RH, non condensation
PC42d Printing Speed, Resolution and General Specifications of Medium
Printing Mode:
Direct thermo-sensitive
Printing Speed (Variable):
50, 75 and 100 mm/s (2, 3 and 4 ips)
Resolution:
203 dph：8 dots/mm
Printing Width:
Maximum 104 mm (4.09 in)
Medium Width:
25.4-110 mm (0.99 - 4.33 in)
Label Roll Diameter (Maximum):
127 mm (5 in)
Label Length (Minimum):
9.6 mm (0.38 in)
Interval between Labels:
2-4.5 mm (0.08 - 0.18 in)
Black Label Length:
Can be adjusted by 3-5 mm (0.12 - 0.19 in) from center to left
Medium Thickness:
0.0762-0.224 mm (3 - 8.8 mil)
Lining Opacity (Maximum):
58% (TAPPI T425)

Honeywell PC42d Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Display	-
Product color	Black
Ethernet LAN	Yes
USB 2.0 ports quantity	1
Flash memory	128 MB
Internal memory	64 MB
Built-in barcodes	1D, 2D, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code
Core diameter	38.1 mm
Maximum label width	110 mm
Maximum label length	0.99 m
Maximum roll diameter	128 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	15 - 80 %

Weight and Dimensions

Depth	174 mm
Width	184 mm
Height	222.5 mm
Weight	1500 g
