Honeywell PC42d User Manual

Chapter 1: About the Printer
4 User Instructions for PC42d Desktop Printer
Using Printer Button (continued)
Printer Button Operation
Description
Press and release the printer button
If the printer is in ‘idle’ mode, it will begin to feed
paper until it reaches the initial position of the
next label.
If printing is in progress, it will be suspended.
If printing has been suspended, it will restart.
Press the printer button for 3
seconds
If printing has been suspended, the printing job
will be terminated, and all printing jobs will be
discarded. The printer will return to ‘idle’ status.
LED Status Light
The LED status light can be in green, orange or red, with each indicating the printer’s
current status. Use the Table below to view the corresponding status of the LED light’s
color.
LED Status Light
LED Status
Description
Off
The printer is not connected to power.
Steady green color
The printer is in ‘idle’ mode and awaits the next
printing job.
Green flickering light after activation
There is an error in the printer’s RAM and
firmware upgrade is required. See “Firmware
Upgrade” on Page 22 for more information.
LED Status Light

Honeywell PC42d Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Display	-
Product color	Black
Ethernet LAN	Yes
USB 2.0 ports quantity	1
Flash memory	128 MB
Internal memory	64 MB
Built-in barcodes	1D, 2D, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code
Core diameter	38.1 mm
Maximum label width	110 mm
Maximum label length	0.99 m
Maximum roll diameter	128 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	15 - 80 %

Weight and Dimensions

Depth	174 mm
Width	184 mm
Height	222.5 mm
Weight	1500 g
