Honeywell PC42d User Manual

Chapter 1: About the Printer
8 User Instructions for PC42d Desktop Printer
5. Adjust the sensor’s position in accordance with the Table below:
Type of Medium
Position of Sensor
Black Label
Below the Black Mark
Gap
Aligned with left triangular mark
Other media
Aligned with right triangular mark (default
position)
Move the sensor to the triangular mark on the left of the ‘gap’ medium
Note:
1. When moving the sensor position, the user would need to re-align the paper;
otherwise the printing position may be inaccurate or paper-feeding may stop because
of incorrect position when pressing the “FEED” button, or flickering red light which is an
indication of irregularity.
2. When a user switches between different types of paper, the user must re-align the
papers each time. Otherwise the printing position may be inaccurate or paper-feeding
may stop because of incorrect position when pressing the “FEED” button, or flickering
red light which is an indication of irregularity.

Honeywell PC42d Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Display	-
Product color	Black
Ethernet LAN	Yes
USB 2.0 ports quantity	1
Flash memory	128 MB
Internal memory	64 MB
Built-in barcodes	1D, 2D, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code
Core diameter	38.1 mm
Maximum label width	110 mm
Maximum label length	0.99 m
Maximum roll diameter	128 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	15 - 80 %

Weight and Dimensions

Depth	174 mm
Width	184 mm
Height	222.5 mm
Weight	1500 g
