54 SF61 Cordless Scanner User’s Guide
Ambient light 0 to 100 000 lux
Bluetooth Radio
Radio Type Bluetooth Class 1 version 2.1 + EDR
Frequency 2400 - 2483.5 MHz
Scanning Performance
SF61BHP Scan angles: 34.4° horizontal, 22.2° vertical
Framing angles: 30° horizontal, 20° vertical
Minimum X dimension 1D: 4 mils (0.1 mm)
Minimum X dimension 2D: 6.6 mils (0.17 mm)
Minimum print contrast: 20%
Barcode Symbologies for 2D Models (SF61BHP)
Australian Post Han Xin Code
Aztec Infomail
BPO Intelligent mail
Canada Post Interleaved 2 of 5
Codabar Japan Post
Codablock A Matrix 2 of 5
Codablock F Maxicode
Code 11 Micro PDF417
Code 39 MSI
Code 93/93i Multicode
Code 128 / GS1-128 PDF417
DataMatrix Planet
Dutch Post Plessey
EAN/UPC Postnet
GS1 Composite QR Code
GS1 DataBar Expanded Standard 2 of 5
GS1 DataBar Limited Sweden Post
GS1 DataBar Omni-Directional Telepen
GS1 DataBar Stacked TLC 39
Temperature and Environmental Specifications
