APPENDIX
A
SF61 Cordless Scanner User’s Guide 53
SPECIFICATIONS AND READING
DISTANCES
Specifications
Use this section to find technical information about the SF61B scanner models.
Physical Dimensions
Length 15.6 cm (6.1 in) with magnet end-cap
16.0 cm (6.3 in) with ring end-cap
Height 3.9 cm (1.5 in)
Width 4.6 cm (1.8 in)
Weight 185.5 g (6.5 oz) with the battery
137 g (4.8 oz) without the battery
Battery = 48.5 g (1.7 oz)
Power and Electrical Specifications
Operating Rechargeable lithium-ion battery (2730 mAh)
Electrical rating x 5V, 2A
ESD sensitivity ± 8 kV (air discharge)
± 4 kV (contact discharge)
Temperature and Environmental Specifications
Operating -20°C to 50°C (-4°F to 122°F)
Storage -40 °C to 70°C (-40 °F to 158 °F)
Charging 0°C to 45°C (32°F to 113°F)
Relative humidity 5 to 95% non-condensing
Shock 40G, half sinus, 6 ms, 6 directions
Vibrations 8G, from 10Hz to 500Hz, 2hr/axis, 3 axes
Tumble test 2000 tumbles at 1m height
Environmental IP65
