Honeywell Voyager 1202G User Manual

7 - 1
7
Symbologies
This programming section contains the following menu selections. Refer to
Chapter 10 for settings and defaults.
All Symbologies
If you want to decode all the symbologies allowable for your scanner, scan the
All Symbologies On code. If on the other hand, you want to decode only a
particular symbology, scan All Symbologies Off followed by the On symbol for
that particular symbology.
• All Symbologies • GS1-128
• Airline Code 5 - see Straight 2 of 5
IATA (two-bar start/stop)
• Interleaved 2 of 5
• China Post (Hong Kong 2 of 5) • ISBT 128
• Codabar • Matrix 2 of 5
• Code 11 • MSI
• Code 128 • NEC 2 of 5
• Code 32 Pharmaceutical (PARAF) • Plessey Code
• Code 39 • Postal Codes
• Code 93
• Straight 2 of 5 IATA (two-bar start/
stop)
•EAN/JAN-13
• Straight 2 of 5 Industrial (three-bar
start/stop)
• EAN/JAN-8 • Telepen
• GS1 DataBar Expanded • Trioptic Code
• GS1 DataBar Limited • UPC-A
• GS1 DataBar Omnidirectional
• UPC-A/EAN-13 with Extended
Coupon Code
• GS1 Emulation • UPC-E0
All Symbologies On
All Symbologies Off

Honeywell Voyager 1202G Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Scanner type	1D
Pitch reading angle	60 - 60 °
Linear (1D) barcodes supported	-
Wireless range	10 m
Bluetooth version	2.1+EDR
Operating frequency	2.4 - 2.5 MHz
Standard interfaces	Bluetooth
Connectivity technology	Wireless
Battery life	12 h
Charging time	4 h
Input voltage	5 V
Battery capacity	1800 mAh
Power source type	Battery
Number of reads per charge	45000
Product color	Black
International Protection (IP) code	IP42
Storage temperature (T-T)	-5 - 35 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Sustainability certificates	RoHS
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	180 mm
Width	66 mm
Height	92 mm
Weight	180 g
Base weight	185 g
Base dimensions	200 x 67 x 97 mm
