7 - 41
scanning the bar code below, then setting the timeout (from 0-65535 milli-
seconds) by scanning digits from the Programming Chart, then scanning
Save.
Default = 100.
Note: The Addenda Timeout setting is applied to all addenda and coupon
code searches.
UPC-E0
<Default All UPC-E0 Settings>
UPC-E0 On/Off
Most U.P.C. bar codes lead with the 0 number system. To read these
codes, use the UPC-E0 On selection. If you need to read codes that lead
with the 1 number system, use EAN/JAN-13 (page 7-45).
Default = On.
UPC-E0 Expand
UPC-E Expand expands the UPC-E code to the 12 digit, UPC-A format.
Default = Off.
Addenda Timeout
* UPC-E0 On
UPC-E0 Off
On
* Off

Table of Contents

Other manuals for Honeywell Voyager 1202G

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Honeywell Voyager 1202G and is the answer not in the manual?

Honeywell Voyager 1202G Specifications

General IconGeneral
TypeHandheld bar code reader
Sensor typeLaser
Scanner type1D
Pitch reading angle60 - 60 °
Linear (1D) barcodes supported-
Wireless range10 m
Bluetooth version2.1+EDR
Operating frequency2.4 - 2.5 MHz
Standard interfacesBluetooth
Connectivity technologyWireless
Battery life12 h
Charging time4 h
Input voltage5 V
Battery capacity1800 mAh
Power source typeBattery
Number of reads per charge45000
Product colorBlack
International Protection (IP) codeIP42
Storage temperature (T-T)-5 - 35 °C
Operating temperature (T-T)5 - 40 °C
Operating relative humidity (H-H)0 - 95 %
Sustainability certificatesRoHS
Harmonized System (HS) code84716070
Weight and Dimensions IconWeight and Dimensions
Depth180 mm
Width66 mm
Height92 mm
Weight180 g
Base weight185 g
Base dimensions200 x 67 x 97 mm
