Honeywell Voyager 1202G User Manual

2 - 16
Autocaps via NumLock bar code should be scanned in countries (e.g.,
Germany, France) where the Caps Lock key cannot be used to toggle Caps
Lock. The NumLock option works similarly to the regular Autocaps, but
uses the NumLock key to retrieve the current state of the Caps Lock.
Emulate External Keyboard should be scanned if you do not have an
external keyboard (IBM AT or equivalent).
Note: After scanning the Emulate External Keyboard bar code, you must
power cycle your computer.
Keyboard Conversion
Alphabetic keyboard characters can be forced to be all upper case or all
lowercase. So if you have the following bar code: “abc569GK,” you can
make the output “ABC569GK” by scanning Convert All Characters to
Upper Case, or to “abc569gk” by scanning Convert All Characters to
Lower Case. These settings override Keyboard Style selections.
Default = Keyboard Conversion Off .
Keyboard Modifiers
This modifies special keyboard features, such as CTRL+ ASCII codes and
Turbo Mode.
Autocaps via NumLock
Emulate External Keyboard
* Keyboard Conversion Off
Convert All Characters to Upper
Case
Convert All Characters to Lower
Case

Honeywell Voyager 1202G Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Scanner type	1D
Pitch reading angle	60 - 60 °
Linear (1D) barcodes supported	-
Wireless range	10 m
Bluetooth version	2.1+EDR
Operating frequency	2.4 - 2.5 MHz
Standard interfaces	Bluetooth
Connectivity technology	Wireless
Battery life	12 h
Charging time	4 h
Input voltage	5 V
Battery capacity	1800 mAh
Power source type	Battery
Number of reads per charge	45000
Product color	Black
International Protection (IP) code	IP42
Storage temperature (T-T)	-5 - 35 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Sustainability certificates	RoHS
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	180 mm
Width	66 mm
Height	92 mm
Weight	180 g
Base weight	185 g
Base dimensions	200 x 67 x 97 mm
