Honeywell Voyager 1202G User Manual

11 - 3
Voyager 1202g Product Specifications
Parameter Specification
Mechanical
Height
3.6 in. (92mm)
Length
7.1 in. (180mm)
Width
2.6 in. (66mm)
Weight (includes battery)
6.3 oz. (180g)
Battery
Lithium Ion
1800 mAHr minimum
Number of Scans
Up to 45,000 per charge
Expected Hours of Operation
12
Expected Charge Time
4 hours (external supply)
8 hours (USB power)
Radio
Frequency
2.4 to 2.5 GHz (ISM Band) Frequency Hopping
Bluetooth v.2.1
Range
33 ft. (10 m) typical line of sight
Data Rate
Up to 3 MBps
Environmental
Temperature Ranges:
Operating - Charging
41° F to +104° F (5° C to 40° C)
Operating - Non-Charging
32° F to +122° F (0° C to 50° C)
Storage*
23°F to +95°F (-5°C to 35°C)
Humidity
0 to 95% relative humidity, non-condensing
Mechanical Drop
Designed to withstand 30 drops from 5 feet (1.5m) to
concrete
Environmental Sealing
IP42
ESD Sensitivity
16kV air
9kV contact
Scan Performance
Pitch, Skew
60°, 60°

Honeywell Voyager 1202G Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Scanner type	1D
Pitch reading angle	60 - 60 °
Linear (1D) barcodes supported	-
Wireless range	10 m
Bluetooth version	2.1+EDR
Operating frequency	2.4 - 2.5 MHz
Standard interfaces	Bluetooth
Connectivity technology	Wireless
Battery life	12 h
Charging time	4 h
Input voltage	5 V
Battery capacity	1800 mAh
Power source type	Battery
Number of reads per charge	45000
Product color	Black
International Protection (IP) code	IP42
Storage temperature (T-T)	-5 - 35 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Sustainability certificates	RoHS
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	180 mm
Width	66 mm
Height	92 mm
Weight	180 g
Base weight	185 g
Base dimensions	200 x 67 x 97 mm
