Vuquest 3320g User Guide 135
Data Matrix
< Default All Data Matrix Settings >
Data Matrix On/Off
Data Matrix Message Length
Scan the bar codes below to change the message length. Refer to Message Length
Description (page 92) for additional information. Minimum and Maximum lengths
= 1-3116. Minimum Default = 1, Maximum Default = 3116.
Data Matrix Code Page
Data Matrix Code pages define the mapping of character codes to characters. If
the data received does not display with the proper characters, it may be because
the bar code being scanned was created using a code page that is different from
the one the host program is expecting. If this is the case, scan the bar code below,
select the code page with which the bar codes were created (see Symbology Charts
on page 209), and scan the value and the Save bar code from the on the inside the
back cover of this manual. The data characters should then appear properly.
