CHAPTER
11
Vuquest 3320g User Guide 197
PRODUCT SPECIFICATIONS
3320 Scanner Product Specifications
Parameter Specification
Dimensions (Typical):
Height
1.0 inches (26mm)
Length
2.9 inches (73mm)
Width
2.0 inches (51mm)
Weight
2.7 ounces (77g)
Wavelength:
Illumination LED
633nm
Aimer LED
528nm
Image Size 844 x 640 pixels
Skew Angle +
65°
Pitch Angle +45°
Motion Tolerance:
Enhanced Streaming Presentation Trigger
SR, HD version: up to 200 inches per second for 13 mil
UPC
ER version: up to 106 inches per second for 13 mil UPC
Symbol Contrast Grade 1.0 (20% or greater)
Voltage Requirements 4 - 5.5 VDC at input connector
Current Draw @5VDC Scanning Standby
450mA, 2.3W90mA, 0.45W
Power Supply Noise Rejection Maximum 100mV peak to peak, 10 to 100 kHz
Temperature Ranges:
Operating
-4F to +122F (-20C to 50C)
Storage
-4F to +158F (-20C to 70C)
Humidity 5 to 95% non-condensing
