Task Command
Display the IP configuration of Layer 3 interfaces. display ip interface brief
Display information about active routes in the routing table. display ip routing-table
Display VLAN settings. display vlan
Display the spanning tree status and statistics. display stp brief
Connecting the switch to the network
Before you connect the switch to the network, verify that all its basic settings are correct.
Connecting your switch to the network through twisted pair
cables
You can connect the 10/100Base-TX ports, 1000Base-T ports, and 10GBASE-T ports on your switch to
the network. These ports use RJ-45 connectors and support MDI/MDI-X auto-sensing. Use category-6A
or category-7 twisted pair cables to connect 10GBASE-T ports and category-5 or above to connect other
ports. For more information about twisted pair cables, see "Appendix D Cables."
To connect a 10/100Base-TX port, a 1000Base-T port, or a 10GBASE-T port to a peer device:
1. Connect one end of a twisted pair cable to the port.
2. Connect the other end of the twisted pair cable to the RJ-45 Ethernet port of the peer device.
3. Verify the port LEDs for incorrect connection.
For more information about the LED status, see "Appendix C LEDs."
Connecting your switch to the network through optical fibers
W
ARNING!
To avoid injury to your eyes, do not stare at the optical fiber interfaces and optical fiber connectors when
connecting optical fibers.
You can install a transceiver module (see "Installing FRUs") in a fiber port and use optical fibers to
connect the port to the network. For more information about optical fibers, see "Appendix D Cables."
To connect a fiber port to a peer device through optical fibers:
1. Install a transceiver module into the port.
2. Remove the dust cover of the optical fiber connector, and clean the end of the optical fiber.
3. Remove the dust plug of the transceiver module, connect one end of the optical fiber to the
transceiver module, and connect the other end to the transceiver module in the peer device.
{ For how to connect an LC connector, see Figure 36.
{ For how to connect an MPO connector, see Figure 37.
4. Examine the port LEDs for incorrect connection.
For more information about the LED status, see "Appendix C LEDs."
