62
Fan tra
y
Wei
g
ht Hei
g
ht
Width
De
p
th
10508-V fan tray 8.3 kg (18.30 lb) 80 mm (3.15 in) 440 mm (17.32 in) 654 mm (25.75 in)
10512 upper fan
tray
4.49 kg (9.90 lb) 84 mm (3.31 in) 301 mm (11.85 in) 646 mm (25.43 in)
10512 lower fan
tray
3.61 kg (7.96 lb) 84 mm (3.31 in) 301 mm (11.85 in) 646 mm (25.43 in)
Module power consumption and system power
consumption
Card power consumption
The power consumption of the cards depends on the card model and state. Table 16 shows the power
consumption for different card models.
• The static power consumption of a card refers to the power consumed by the card when the card is
running but all ports on the card are down and when no transceiver module is available on the
optical interface of the card.
• The dynamic power consumption of a card refers to the power consumed by the card when all the
ports on the card are link up and send broadcasts.
Table 16 Card power consumption
Model
Minimum static power
consum
p
tion
Maximum dynamic power
consum
p
tion
LSU1SUPA0 38 W 50 W
LSU1SUPB0 45 W 50 W
LSU1TGS16SC0 84 W 115 W
LSU1TGS8SE0 104 W 135 W
LSU1GT48SE0 67 W 95 W
LSU1GP48SE0 44 W 95 W
LSU1GP24TXSE0 54 W 95 W
LSU1GP24TSE0 47 W 75 W
LSU1TGX4SE0 53 W 80 W
LSU1TGS32SF0 126 W 170 W
LSU1TGS48SF0 164 W 255 W
LSU1QGS4SF0 82 W 100 W
LSU1QGS8SF0 100 W 135 W
LSU1QGC4SF0 53 W 85 W
LSU1CGC2SE0 163 W 220 W
LSU1TGT24SF0 103 W 190 W
