HP 10504 - Fan Tray Power Consumption

63
Model
Minimum static power
consum
p
tion
Maximum dynamic power
consum
p
tion
LSU1TGS8EA0 111 W 140 W
LSU1GT48EA0 67 W 95 W
LSU1GP48EA0 44 W 95 W
LSU1GP24TXEA0 54 W 95 W
LSU1TGX4EA0 53 W 80 W
LSU1TGS8EB0 117 W 170 W
LSU1GP48EB0 43 W 110 W
LSU1GP24TXEB0 51 W 100 W
LSU1TGX4EB0 53 W 80 W
LSU1FAB04A0 41 W 50 W
LSU1FAB08A0 68 W 85 W
LSU1FAB04B0 48 W 65 W
LSU1FAB04D0 60 W 80 W
LSU1FAB08B0 44 W 60 W
LSU1FAB08D0 101 W 135 W
LSU1FAB12B0 107 W 140 W
LSU1FAB12D0 195 W 255 W
LSU3WCMD0 118 W 150 W
LSU1FWCEA0 109 W 157 W
Fan tray power consumption
The switch uses fans with the automatic speed adjustment function. The fan speed is automatically
adjusted based on the heat dissipation condition of the switch. The power consumed by a fan tray
depends on the fan speed. Table 17 sho
ws the power consumption of different fan trays.
Table 17 Fan tray power consumption
Model
Minimum fan tray power
consum
p
tion
Maximum fan tray power
consum
p
tion
10504 12 W 240 W
10508 11 W 234 W
10508-V 13 W 329 W
10512 (upper fan tray) 9 W 200 W
10512 (lower fan tray) 7 W 124 W
