(4) Fan tray slot
Location of the fan tray slot:
• 10504, 10508, and 10512—Left
rear of the chassis
• 10508-V—Upper rear of the
chassis
Every 10500 switch comes with one or two fan
trays. You do not need to order fan trays.
(5) Switching
fabric module
slots
Both switching fabric modules and
switching fabric module slots have
silver gray edges.
A 10500 switch requires two to four switching
fabric modules, and one of them must be installed
in one of the two lowest numbered switching fabric
module slots.
For more information about available cards, power supplies, and fan trays, see "Appendix B FRUs and
compatibility matrixes."
Weights and dimensions
Table 12 Switch weights and dimensions
Model Wei
th
10504 < 85 kg (187.39 lb)
353 mm (13.90 in)
(8 RU)
440 mm (17.32
in)
660 mm (25.98
in)
10508
< 125 kg (275.57
lb)
620 mm (24.41 in)
(14 RU)
440 mm (17.32
in)
660 mm (25.98
in)
10508-V
< 145 kg (319.66
lb)
886 mm (34.88 in)
(20 RU)
440 mm (17.32
in)
660 mm (25.98
in)
10512
< 165 kg (363.76
lb)
797 mm (31.38 in)
440 mm (17.32
in)
660 mm (25.98
in)
NOTE:
Rack height is measured in RUs. One RU is 44.45 mm (1.75 in).
Table 13 Card weights and dimensions
Card model Wei
th
LSU1SUPA0 2.83 kg (6.24 lb) 40 mm (1.57 in) 399 mm (15.71 in) 352 mm (13.86 in)
LSU1SUPB0 2.97 kg (6.55 lb) 40 mm (1.57 in) 399 mm (15.71 in) 352 mm (13.86 in)
LSU1TGS16SC0 3.29 kg (7.25 lb) 40 mm (1.57 in) 399 mm (15.71 in) 352 mm (13.86 in)
LSU1TGS8SE0 3.03 kg (6.68 lb) 40 mm (1.57 in) 399 mm (15.71 in) 352 mm (13.86 in)
LSU1GT48SE0 3.31 kg (7.30 lb) 40 mm (1.57 in) 399 mm (15.71 in) 352 mm (13.86 in)
LSU1GP48SE0 3.25 kg (7.16 lb) 40 mm (1.57 in) 399 mm (15.71 in) 352 mm (13.86 in)
LSU1GP24TXSE0 3.08 kg (6.79 lb) 40 mm (1.57 in) 399 mm (15.71 in) 352 mm (13.86 in)
LSU1GP24TSE0 3.01 kg (6.64 lb) 40 mm (1.57 in) 399 mm (15.71 in) 352 mm (13.86 in)
LSU1TGX4SE0 2.93 kg (6.46 lb) 40 mm (1.57 in) 399 mm (15.71 in) 352 mm (13.86 in)
LSU1TGS32SF0 3.45 kg (7.61 lb) 40 mm (1.57 in) 399 mm (15.71 in) 352 mm (13.86 in)
