Appendix B FRUs and compatibility matrixes
This appendix describes the FRUs available for the switch and their compatibility.
All the FRUs listed in this appendix are hot swappable.
MPUs
CAUTION:
Use the Comware V5 software (with the version number R1XXX) for the LSU1SUPA0. Use the Comware
V
7 software (with the version number R2XXX) for the LSU1SUPB0.
MPU is the supervisor engine and core of the control management plane for the switch. The switch
supports the MPUs LSU1SUPA0 and LSU1SUPB0. They are applicable to all 10500 switch models.
MPUs are ordered separately. The switch requires one MPU to operate correctly. You can also install two
MPUs of the same model for redundancy.
Table 20 de
scribes the MPU specifications, and Table 21 shows the MPU product code and model
matrix.
Table 20 MPU specifications
Item Descri
p
tion
Interfaces
• One console port for local or remote dialup configuration management
• One 10/100/1000BASE-T interface for management and upgrade
Interface transmission
rate
• Console port—No greater than 115200 bps and defaults to 9600 bps
• 10/100/1000BASE-T interface—10/100/1000 Mbps
Cables and max
transmission distance
• Console port—15 m (49.21 ft) over common asynchronous serial interface cable
• 10/100/1000BASE-T interface—100 m (328.08 ft) over Category-5 twisted
pairs
Table 21 MPU product code and model matrix
MPU model Product code
HP descri
p
tion
LSU1SUPA0
JC614A
JG375A
HP 10500 Main Processing Unit
HP 10500 TAA-compliant Main Processing Unit
LSU1SUPB0 JG496A
HP 10500 Type A Main Processing Unit with Comware V7 Operating
System
LPUs
The LPUs in Table 22 are compatible with all 10500 switches. Table 23 lists their product codes and
descriptions. For more information about the transceiver modules that each LPU supports, see
"Transceiver modules."
