QSFP+ to SFP+ cable
A QSFP+ to SFP+ cable is a cable with one QSFP+ module at one end and four SFP+ modules at the
other end.
Figure 53 QSFP+ to SFP+ cable
(1) QSFP+ connector (2)
QSFP+ pull latch
(3) SFP+ connector (4) SFP+ pull latch
1
2
34
