HP 10504 - Power Supplies; Fan Trays

72
Switching fabric
model
Product
code
HP description
LSU1FAB12D0
JC750A
JG339A
HP 10512 3.44Tbps Type D Fabric Module
HP 10512 3.44Tbps Type D Fabric TAA-compliant Module
Power supplies
The switch supports the HP 10500 2500W AC Power Supply (JC610A) and HP 10500 2400W DC
Power Supply (JC747A). The HP 10500 2500W AC Power Supply is an AC-input, DC-output power
supply and provides a maximum DC output power of 2500 W. The HP 10500 2400W DC Power Supply
is a DC-input, DC-output power supply that provides a maximum DC output power of 2400 W.
Table 26 Power supply specifications
Item 2500W AC
2400W DC
Rated input voltage range 100 VAC to 240 VAC @ 50/60 Hz
–48 VDC to –60 VDC
Rated output voltage 12 VDC 12 VDC
Maximum input current 16 A 60 A
Maximum output current
• 208 A (220 VAC)
• 100 A (110 VAC)
200 A
Maximum output power
• 1200 W (110 VAC)
• 2500 W (220 VAC)
2400 W
Temperature requirements
• Operating temperature: –10°C to +50°C (14°F to 122°F)
• Storage temperature: –40°C to +85°C (–40°F to +185°F)
You can select a certain number of power supplies according to the actual power consumption
requirements of your switch. Make sure the total maximum output power of the ordered power supplies
is greater than the system power consumption. HP recommends that you reserve 20% of the maximum
output power.
IMPORTANT:
• Power supplies of different models cannot be installed on the same switch.
• When the temperature of a power supply exceeds the acceptable operating temperature, the power
supply is automatically powered off. When the temperature recovers to the acceptable temperature, the
power supply is automatically powered on.
Fan trays
Table 27 shows the fan trays that each 10500 switch chassis supports. Every 10500 switch comes with
one fan tray installed.
