Page #104 background imageLoading...
Page #104 background image
NOTE: If your computer does not automatically restart in HP Recovery Manager, change the computer
boot order, and then follow the on-screen instructions. See Changing the computer boot order
on page 96.
Changing the computer boot order
If your computer does not restart in HP Recovery Manager, you can change the computer boot order. This is
the order of devices listed in BIOS where the computer looks for startup information. You can change the
selection to an optical drive or a USB ash drive, depending on the location of your HP Recovery media.
To change the boot order:
IMPORTANT: For a tablet with a detachable keyboard, connect the tablet to the keyboard base before
beginning these steps.
1. Insert the HP Recovery media.
2. Access the system Startup menu.
For computers or tablets with keyboards attached:
Turn on or restart the computer or tablet, quickly press esc, and then press f9 for boot options.
For tablets without keyboards:
Turn on or restart the tablet, quickly hold down the volume up button, and then select f9.
or –
Turn on or restart the tablet, quickly hold down the volume down button, and then select f9.
3. Select the optical drive or USB ash drive from which you want to boot, and then follow the on-screen
instructions.
Removing the HP Recovery partition (select products only)
HP Recovery Manager software allows you to remove the HP Recovery partition (select products only) to free
up hard drive space.
IMPORTANT: After you remove the HP Recovery partition, you will not be able to perform System Recovery
or create HP Recovery media. Before removing the Recovery partition, create HP Recovery media. See
Creating HP Recovery media (select products only) on page 92.
Follow these steps to remove the HP Recovery partition:
1. Type recovery in the taskbar search box, and then select HP Recovery Manager.
2. Select Remove Recovery Partition, and then follow the on-screen instructions.
96 Chapter 10 Backing up, restoring, and recovering

Table of Contents

Other manuals for HP 280 G3

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP 280 G3 and is the answer not in the manual?

HP 280 G3 Specifications

General IconGeneral
Memory slots2x DIMM
Internal memory8 GB
Memory clock speed2666 MHz
Internal memory typeDDR4-SDRAM
Maximum internal memory32 GB
Tjunction100 °C
Processor cache9 MB
Processor cores6
System bus rate8 GT/s
Processor familyIntel® Core™ i5
Processor socketLGA 1151 (Socket H4)
Processor frequency3 GHz
Processor cache typeSmart Cache
Processor lithography14 nm
Processor manufacturerIntel
PCI Express slots version3.0
Processor boost frequency4.4 GHz
Processor operating modes64-bit
PCI Express configurations1x8+2x4, 1x16, 2x8
Thermal Design Power (TDP)65 W
Number of processors installed1
Maximum number of PCI Express lanes16
Memory bandwidth supported by processor (max)41.6 GB/s
Maximum internal memory supported by processor128 GB
HDD speed7200 RPM
HDD interfaceSATA
Storage mediaHDD
Total HDDs capacity1000 GB
Card reader integrated-
On-board graphics cardYes
On-board graphics card ID0x3E92
On-board graphics card modelIntel® UHD Graphics 630
Maximum on-board graphics card memory64 GB
On-board graphics card OpenGL version4.5
On-board graphics card base frequency350 MHz
On-board graphics card DirectX version12.0
On-board graphics card dynamic frequency (max)1100 MHz
Number of displays supported (on-board graphics)3
Microphone inNo
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
Chassis typeSFF
Product colorBlack
Placement supportedHorizontal/Vertical
Product typePC
Motherboard chipsetIntel® H370
HP segmentBusiness
Ethernet LAN data rates10, 100, 1000 Mbit/s
Power supply180 W
Scalability1S
Processor ARK ID134895
Processor package size37.5 x 37.5 mm
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Thermal solution specificationPCG 2015C
Weight and Dimensions IconWeight and Dimensions
Depth296 mm
Width95 mm
Height270 mm
Weight4200 g
