Front bezel
1. Prepare the computer for disassembly (Preparation for disassembly on page 15).
2. Remove the access panel (Access panel on page 16).
3. Pull the four tabs upward (1), and then rotate the bezel o the computer (2).
IMPORTANT: A cable connects the power button in the bezel to the system board.
To install the front bezel, reverse the removal procedure.
Front bezel 21
