Rear panel components
Item Component Item Component
1 Line-in microphone connector (pink) 7 Serial port
2 Line-in audio connector (blue) 8 USB ports
3 Line-out connector for powered audio devices
(green)
9 RJ-45 network connector
4 HDMI port* 10 USB ports (4)
5 Security lock slot 11 Power cord connector
6 VGA monitor connector*
NOTE: When a graphics card is installed in one of the system board slots, the video connectors on the rear panel are covered.
The system board graphics can be disabled by changing settings in Computer Setup.
Rear panel components 3
