Page #97 background image
NOTE: If you need to stop a diagnostic test, press esc.
Starting HP PC Hardware Diagnostics UEFI
To start HP PC Hardware Diagnostics UEFI, follow these steps:
1. Turn on or restart the computer, and quickly press esc.
2. Press f2.
The BIOS searches three places for the diagnostic tools, in the following order:
a. Connected USB ash drive
NOTE: To download the HP PC Hardware Diagnostics UEFI tool to a USB ash drive, see
Downloading the latest HP PC Hardware Diagnostics UEFI version on page 89.
b. Hard drive
c. BIOS
3. When the diagnostic tool opens, select the type of diagnostic test you want to run, and then follow the
on-screen instructions.
Downloading HP PC Hardware Diagnostics UEFI to a USB ash drive
Downloading HP PC Hardware Diagnostics UEFI to a USB ash drive can be useful in the following situations:
HP PC Hardware Diagnostics UEFI is not included in the preinstall image.
HP PC Hardware Diagnostics UEFI is not included in the HP Tool partition.
The hard drive is damaged.
NOTE: The HP PC Hardware Diagnostics UEFI download instructions are provided in English only, and you
must use a Windows computer to download and create the HP UEFI support environment because only .exe
les are provided.
Downloading the latest HP PC Hardware Diagnostics UEFI version
To download the latest HP PC Hardware Diagnostics UEFI version to a USB ash drive:
1. Go to http://www.hp.com/go/techcenter/pcdiags. The HP PC Diagnostics home page is displayed.
2. In the HP PC Hardware Diagnostics UEFI section, select Download UEFI Diagnostics, and then select
Run.
Downloading HP PC Hardware Diagnostics UEFI by product name or number (select products
only)
NOTE: For some products, it may be necessary to download the software to a USB ash drive by using the
product name or number.
To download HP PC Hardware Diagnostics UEFI by product name or number (select products only) to a USB
ash drive:
1. Go to http://www.hp.com/support.
2. Enter the product name or number, select your computer, and then select your operating system.
3. In the Diagnostics section, follow the on-screen instructions to select and download the specic UEFI
Diagnostics version for your computer.
Using HP PC Hardware Diagnostics UEFI 89

Table of Contents

Other manuals for HP 280 G3

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP 280 G3 and is the answer not in the manual?

HP 280 G3 Specifications

General IconGeneral
Memory slots2x DIMM
Internal memory8 GB
Memory clock speed2666 MHz
Internal memory typeDDR4-SDRAM
Maximum internal memory32 GB
Tjunction100 °C
Processor cache9 MB
Processor cores6
System bus rate8 GT/s
Processor familyIntel® Core™ i5
Processor socketLGA 1151 (Socket H4)
Processor frequency3 GHz
Processor cache typeSmart Cache
Processor lithography14 nm
Processor manufacturerIntel
PCI Express slots version3.0
Processor boost frequency4.4 GHz
Processor operating modes64-bit
PCI Express configurations1x8+2x4, 1x16, 2x8
Thermal Design Power (TDP)65 W
Number of processors installed1
Maximum number of PCI Express lanes16
Memory bandwidth supported by processor (max)41.6 GB/s
Maximum internal memory supported by processor128 GB
HDD speed7200 RPM
HDD interfaceSATA
Storage mediaHDD
Total HDDs capacity1000 GB
Card reader integrated-
On-board graphics cardYes
On-board graphics card ID0x3E92
On-board graphics card modelIntel® UHD Graphics 630
Maximum on-board graphics card memory64 GB
On-board graphics card OpenGL version4.5
On-board graphics card base frequency350 MHz
On-board graphics card DirectX version12.0
On-board graphics card dynamic frequency (max)1100 MHz
Number of displays supported (on-board graphics)3
Microphone inNo
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
Chassis typeSFF
Product colorBlack
Placement supportedHorizontal/Vertical
Product typePC
Motherboard chipsetIntel® H370
HP segmentBusiness
Ethernet LAN data rates10, 100, 1000 Mbit/s
Power supply180 W
Scalability1S
Processor ARK ID134895
Processor package size37.5 x 37.5 mm
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Thermal solution specificationPCG 2015C
Weight and Dimensions IconWeight and Dimensions
Depth296 mm
Width95 mm
Height270 mm
Weight4200 g
