HP 3500 Series Advanced Traffic Management Guide

5-61
Quality of Service: Managing Bandwidth More Effectively
Globally-Configured QoS
Figure 5-27. The Completed VID-DSCP Priority Configuration
The switch will now apply the DSCP policies in figure 5-27 to packets received
on the switch with the specified VLAN-IDs. This means the switch will:
■ Overwrite the original DSCPs in the selected packets with the new DSCPs
specified in the above policies.
■ Assign the 802.1p priorities in the above policies to the appropriate
packets.
HP Switch(config)# vlan 1 qos dscp 000010
HP Switch(config)# vlan 20 qos dscp 000010
HP Switch(config)# vlan 30 qos dscp 000101
HP Switch(config)# vlan 40 qos dscp 000111
HP Switch(config)# show qos vlan-priority
VLAN priorities
VLAN ID Apply rule | DSCP Priority
------- ----------- + ------ -----------
1 DSCP | 000010 1
20 DSCP | 000010 1
30 DSCP | 000101 5
40 DSCP | 000111 7

HP 3500 Series Specifications

General

Model	HP 3500 Series
Layer	Layer 3
MAC Address Table Size	16, 000 entries
Type	Managed
Uplink	SFP
PoE	Optional
Management	Web, CLI, SNMP
Routing Protocol	Static, RIP
Power Supply	Internal
Form Factor	1U rack-mountable
Jumbo Frame Support	Yes
Operating Temperature	32°F to 113°F (0°C to 45°C)
Ports	24 or 48 10/100/1000 ports
