8.
There
are two mass storage locations
in
the
unit.
The
one on
the
right as
you face
the
front panel is called
the
Removeable-media Bay,
and
the
other
is called
the
Non-removeable-media Bay.
The
new drive
must
go
in
the
Removeable-media Bay.
Mass Storage Locations
9.
If
a drive is already installed
in
that
location,
it
must be moved
to
the
other
location or removed from
the
unit.
Note
If
there
is no external SCSI connector on
the
rear
panel,
the
termination must be removed from any drive located in
the
Non-removeable-media Bay.
It
must
be removed
both
in
drives
which have
just
been moved
there
as well as those installed
there
at
the
factory.
10.
Install
the
isolation grommets on
the
drive bracket. Use
the
holes
marked
"DDS".
Put
the
grommet
through
the
large hole,
then
roll
it
into
the
small
hole.
