Illustrated parts catalog 10

Item Description

Original spare

part number

Modified spare

part number

Customer self repair

DVD-ROM drive, removable

slimline, 8X*

268795-001‡

See requirement

397928-001 Yes

Cables

23 SCSI cable kit* 289567-001 — —

a) SCSI cable, short, 68 pin — — Yes

b) SCSI cable, long, 68 pin — — Yes

c) System cable, SCSI, 50 pin — — Yes

24 Signal cable kit* 228518-001 — —

a) Power button/LED board

cable, 14 pin

— — Yes

b) PCI hot-plug LED board

cable

— — Yes

25 Miscellaneous cable kit 366063-001 — —

a) Diskette drive cable* — — Yes

b) CD multibay adaptor cable* — — Yes

c) USB cable and connector — — Yes

Rack mounting hardware

26 2U Quick Deploy Rail System* 359254-001 — Yes

Miscellaneous

27 Hardware kit* 228527-001 — —

a) Screws, T-15, flat-head — — Yes

b) Expansion slot cover — — Yes

c) Screws, 6-32 — — Yes

28 Plastics kit* 359720-001 — —

a) PCI slot release lever — — Yes

b) PCI lightpipe, rear — — Yes

c) PCI lightpipe, cover — — Yes

d) PCI riser cage door latch — — Yes

e) Thumbscrew with molded

cap, PCI slot 1

— — Yes

f) Standoff — — Yes

g) Plastic standoff 0.134 in — — Yes

h) Battery clip — — Yes

i) PCI card guide retainer — — Yes

j) Thumbscrew knob — — Yes

k) Diskette drive cover slot — — Yes

29 AC power cord* 187335-001 — Yes

Questions and Answers:

Need help?

Do you have a question about the HP DL380 Generation 4 and is the answer not in the manual?

HP DL380 Generation 4 Specifications

General

Processor	Intel Xeon
Processor Socket	Socket 604
Maximum Processors	2
Chipset	Intel E7520
Memory Slots	8
Maximum Memory	32 GB
RAID	RAID 0, 1, 5
Form Factor	2U Rack
Memory Type	DDR2
Storage	SAS or SATA
Storage Controller	Smart Array 6i
Power Supply	Redundant Power Supply Optional
Operating System Support	Windows Server, Linux
Expansion Slots	6 total: 2 PCI-X, 2 PCI, 2 PCI-Express
