Illustrated parts catalog 6
Illustrated parts catalog
In this section
Customer self repair ................................................................................................................................. 6
Mechanical components (SCSI model) ........................................................................................................ 7
System components (SCSI model)............................................................................................................... 8
Mechanical components (SAS model)....................................................................................................... 12
System components (SAS model).............................................................................................................. 13
Customer self repair
What is customer self repair?
HP's customer self-repair program offers you the fastest service under either warranty or contract. It
enables HP to ship replacement parts directly to you so that you can replace them. Using this program,
you can replace parts at your own convenience.
A convenient, easy-to-use program:
• An HP support specialist will diagnose and assess whether a replacement part is required to address
a system problem. The specialist will also determine whether you can replace the part.
• Replacement parts are express-shipped. Most in-stock parts are shipped the very same day you
contact HP. You may be required to send the defective part back to HP, unless otherwise instructed.
• Available for most HP products currently under warranty or contract. For information on the warranty
service, refer to the HP website
(http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html
).
For more information about HP's customer self-repair program, contact your local service provider. For the
North American program, refer to the HP website (http://www.hp.com/go/selfrepair
).
Customer replaceable parts are identified in the following tables.
