Illustrated parts catalog 7
Mechanical components (SCSI model)
Item Description
Original spare
part number
Modified
spare part
number
Customer
self repair
1 Access panel 359244-001 — Yes
2 Front bezel 359245-001 — Yes
3 Tape drive blank 367666-001 — Yes
4 Hard drive blank 122759-001 — Yes
5
Diskette drive slot cover (see "Plastics Kit,"
Item 28k)
— —
6 Power supply blank 359246-001 — Yes
