Component identification 93

Battery-backed write cache LED statuses

NOTE: This feature applies only to SCSI models.

Server status LED status Battery module status

Server is on and has normal run

time

Green = On Fast charging

Green = Flashing

The microcontroller is waiting for

communication from the host controller.

Green = Off The battery is fully charged.

Amber = On

A short exists in the connection of one or

more of the three button cells within the

battery module.

Amber = Flashing

An open exists in the circuit between the

positive and negative terminals of the battery

module.

Amber = Off Normal

Server is off and is in data

retention mode

Amber = Flashing every

15 seconds

User data held in the write cache is being

backed up.
