Cabling 67
RILOE II cabling
The 30-pin Remote Insight cable ships with the RILOE II cable kit. For more information, refer to the
Remote Insight Lights-Out Edition II User Guide on the Documentation CD.
Internal power cabling
Item Description
1 System power cable
2 Power supply signal cable
3 SCSI power cable

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP DL380 Generation 4 and is the answer not in the manual?

HP DL380 Generation 4 Specifications

General IconGeneral
ProcessorIntel Xeon
Processor SocketSocket 604
Maximum Processors2
ChipsetIntel E7520
Memory Slots8
Maximum Memory32 GB
RAIDRAID 0, 1, 5
Form Factor2U Rack
Memory TypeDDR2
StorageSAS or SATA
Storage ControllerSmart Array 6i
Power SupplyRedundant Power Supply Optional
Operating System SupportWindows Server, Linux
Expansion Slots6 total: 2 PCI-X, 2 PCI, 2 PCI-Express
