HP DL380 Generation 4 User Manual

Removal and replacement procedures 45
NOTE: The server ships standard with five hard drive blanks.
To replace the blank, slide the blank into the bay until it locks into place.
Hot-plug SAS hard drive
To remove the component:
CAUTION: To prevent improper cooling and thermal damage, do not operate the server unless all bays
are populated with either a component or a blank.
1. Determine the status of the hard drive from the hot-plug SAS hard drive LED combinations (on page
87).
2. Back up all server data on the hard drive.
3. Remove the hard drive.
To replace the component, reverse the removal procedure.

HP DL380 Generation 4 Specifications

General

Processor	Intel Xeon
Processor Socket	Socket 604
Maximum Processors	2
Chipset	Intel E7520
Memory Slots	8
Maximum Memory	32 GB
RAID	RAID 0, 1, 5
Form Factor	2U Rack
Memory Type	DDR2
Storage	SAS or SATA
Storage Controller	Smart Array 6i
Power Supply	Redundant Power Supply Optional
Operating System Support	Windows Server, Linux
Expansion Slots	6 total: 2 PCI-X, 2 PCI, 2 PCI-Express
