Illustrated parts catalog 12

If your unit contains a part that is labelled with the Original Spare number, please order the Original Spare as the

replacement part in the EU. In this case either the Original Spare or the Modified Spare may be shipped which will

not affect performance or functionality of the unit.

§Directive 2002/95/EC restricts the use of lead, mercury, cadmium, hexavalent chromium, PBBs and PBDEs in

electronic products.

Mechanical components (SAS model)

Item Description

Original spare

part number

Modified

spare part

number

Customer

self repair

1 Access panel 359244-001 — Yes

2 Front bezel 392614-001 — Yes

3 Hard drive blank 392613-001 — Yes

Diskette drive slot cover (see "Plastics Kit,"

Item 25k)

— —

5 Power supply blank 359246-001 — Yes

Questions and Answers:

Need help?

Do you have a question about the HP DL380 Generation 4 and is the answer not in the manual?

HP DL380 Generation 4 Specifications

General

Processor	Intel Xeon
Processor Socket	Socket 604
Maximum Processors	2
Chipset	Intel E7520
Memory Slots	8
Maximum Memory	32 GB
RAID	RAID 0, 1, 5
Form Factor	2U Rack
Memory Type	DDR2
Storage	SAS or SATA
Storage Controller	Smart Array 6i
Power Supply	Redundant Power Supply Optional
Operating System Support	Windows Server, Linux
Expansion Slots	6 total: 2 PCI-X, 2 PCI, 2 PCI-Express
