Component identification 84
The front panel health LEDs indicate only the current hardware status. In some situations, HP SIM may
report server status differently than the health LEDs because the software tracks more system attributes.
System LED and color
Internal health LED
color
Status
Processor failure,
socket X (amber)
Red One or more of the following conditions may exist:
• Processor in socket X has failed.
• Processor X is not installed in the socket.
• Processor X is unsupported.
• ROM detects a failed processor during POST.
Amber Processor in socket X is in a pre-failure condition.
PPM failure, slot X
(amber)
Red • PPM in slot X has failed.
• PPM is not installed in slot X, but the corresponding
processor is installed.
DIMM failure, slot X
(amber)
Red • DIMM in slot X has failed.
Amber • DIMM in slot X is in a pre-failure condition.
DIMM failure, all slots
in one bank (amber)
Red No valid or usable memory is installed in the system.
Overtemperature
(amber)
Red
• The Health Driver has detected a cautionary
temperature level.
• The server has detected a hardware critical
temperature level.
Riser interlock (amber) Red PCI riser cage is not seated.
Online spare memory
(amber)
Amber Bank X failed over to the online spare memory bank.
Power converter
module (amber)
Red Power converter module has failed.
Fan (amber) Amber Redundant fan has failed.
Red
The minimum fan requirements are not being met. One or
more fans have failed or are missing.
SCSI configuration
error (amber)*
Red
SCSI cabling or terminator configuration is incorrect for
SCSI backplane.
*This feature applies only to SCSI models.
