116
VlanRoot ID/RPC : 0.00e0-fc0e-6554, 200200
RootPort ID : 128.48
BPDU-Protection : Disabled
TC or TCN received : 2
Time since last TC : 0 days 0h:5m:42s
# In MSTP mode, display the spanning tree status and statistics when the spanning tree feature is
disabled.
<Sysname> display stp
Protocol status : Disabled
Protocol Std. : IEEE 802.1s
Version : 3
Bridge-Prio. : 32768
MAC address : 000f-e200-8048
Max age(s) : 20
Forward delay(s) : 15
Hello time(s) : 2
Max hops : 20
TC Snooping : Disabled
# In PVST mode, display the spanning tree status and statistics when the spanning tree feature is
disabled.
<Sysname> display stp
Protocol status : Disabled
Protocol Std. : IEEE 802.1w (pvst)
Version : 2
Bridge-Prio. : 32768
MAC address : 3822-d69f-0800
Max age(s) : 20
Forward delay(s) : 15
Hello time(s) : 2
TC Snooping : Disabled
Table 26 Command output
Field Description
Bridge ID
Bridge ID, which contains the device's priority and MAC address. For example, in
output 32768.000f-e200-2200, the value preceding the dot is the device's priority.
The value following the dot is the device's MAC address.
Bridge times
Major parameters for the bridge:
• Hello—Hello timer.
• MaxAge—Maximum age timer.
• FwdDelay—Forward delay timer.
• MaxHops—Maximum hops within the MST region.
Root ID/ERPC CIST root ID and external path cost (the path cost from the device to the CIST root).
RegRoot ID/IRPC
CIST regional root ID and internal path cost (the path cost from the device to the
CIST regional root).
VlanRoot ID/RPC
VLAN root ID and root path cost (the path cost from the device to the VLAN root
bridge).
RootPort ID
Root port ID. The value
0.0
indicates that the device is the root and there is no root
port.
