190
all: Specifies all IP subnet-based VLANs.
Examples
# Display information about all IP subnet-based VLANs.
<Sysname> display ip-subnet-vlan vlan all
VLAN ID: 3
Subnet index IP address Subnet mask
0 192.168.1.0 255.255.255.0
Table 42 Command output
Field Description
VLAN ID ID of the IP subnet-based VLAN.
Subnet index Index of the IP subnet.
IP address IP address of the subnet. It can be an IP address or a subnet address.
Subnet mask Mask of the IP subnet.
Related commands
• display ip-subnet-vlan interface
• ip-subnet-vlan
• port hybrid ip-subnet-vlan
ip-subnet-vlan
Use ip-subnet-vlan to associate a VLAN with the specified IP subnet or IP address.
Use undo ip-subnet-vlan to remove the association.
Syntax
ip-subnet-vlan [ ip-subnet-index ] ip ip-address [ mask ]
undo ip-subnet-vlan { ip-subnet-index [ to ip-subnet-end ] | all }
Default
A VLAN is not associated with any IP subnets or IP addresses.
Views
VLAN view
Predefined user roles
network-admin
Parameters
ip-subnet-index: Specifies a beginning IP subnet index in the range of 0 to 65535. The value can be
configured by users. It can also be automatically numbered by the system based on the order in
which the IP subnets or IP addresses are associated with the VLAN.
ip ip-address [ mask ]: Specifies the source IP address or network address based on which the
subnet-based VLANs are classified in dotted decimal notation. The mask argument is the subnet
mask of the source IP address or network address, in dotted decimal notation with a default value of
255.255.255.0.
to ip-subnet-end: Specifies an end IP subnet index of an IP subnet index range, in the range of 0 to
65535. The value for the ip-subnet-end argument must be greater than or equal to the beginning IP
subnet index.
