253
Field Description
Link aggregation supported Indicates whether link aggregation is supported on the port.
Link aggregation enabled Indicates whether link aggregation is enabled on the port.
Aggregation port ID Member port ID, which is 0 when link aggregation is disabled.
Auto-negotiation supported Indicates whether autonegotiation is supported on the port.
Auto-negotiation enabled Indicates whether autonegotiation is enabled on the port.
OperMau Speed and duplex state of the port.
Power port class
PoE port class:
• PSE—Power sourcing equipment.
• PD—Powered device.
PSE power supported Indicates whether the device can operate as a PSE.
PSE power enabled Indicates whether the device is operating as a PSE.
PSE pairs control ability Indicates whether the PSE-PD pair control is available.
Power pairs
Power supply mode:
• Signal—Uses data pairs to supply power.
• Spare—Uses spare pairs to supply power.
Port power classification
Port power classification of the PD:
• Class 0.
• Class 1.
• Class 2.
• Class 3.
• Class 4.
Power type
This field appears only on the devices that support PoE.
PoE device type is Type 2 PSE, which provides a power of 0 W to 30 W,
a voltage of 50 V to 57 V, and a current of up to 600 mA.
Power source
This field appears only on the devices that support PoE.
PSE power type:
• Unknown—Unknown power supply.
• Primary—Primary power supply.
• Backup—Backup power supply.
• Reserved.
Power priority
This field appears only on the devices that support PoE.
PoE power supply priority of PSE ports:
• Unknown.
• Critical.
• High.
• Low.
PD requested power value
This field appears only on the devices that support PoE.
Power (in watts) that the PD requests.
PSE allocated power value
This field appears only on the devices that support PoE.
Power (in watts) that the PSE provides to the PD.
Media policy type
Media policy type:
• unknown.
• voice.
• voiceSignaling.
